1/20 hp 1550 RPM CCW 3.3" Dia 208-230V (Larkin 7163-3371, 253-1195) Fasco # D1103

Part #
D1103
Manufacturer
Fasco
Weight
3.00 LBS
Shipping
Calculated at checkout
Price:
$56.83 RRP:

Description

  • 1/20 hp 1550 RPM, 1.3 amps, 230 Volts 60hz.
  • Shaft: 5/16" x 2 1/4" Rotation = Counter Clockwise SE
  • Stud Mount - Bolt Circle - 2.85"
  • Sleeve Bearings
  • Motor Length Less Shaft = 3"
  • 1 Year Manufacture Warranty

Suggested replacement reference for: JA2N016, JA2N185, JA2N251, JA2P200, JA2P206, JA2S045, 5KSM59GS2780, Replaces Century 575. Larkin Coil Fasco No. 7163-3371, 253-1195. Dayton 32NA52. Not a direct replacement for 253-1194, but is an acceptable replacement. Application Information: Condenser Fan, Cooler: Evaporative, Cooler: Walk-In, Display Case: Refrigerated, Refrigeration Fan. Special Low Temperature Oil.

PDF Documents
