3 hp 3450 RPM 145T 230V Aeration Fan Motor Leeson # 120376

Part #
120376
Manufacturer
Leeson
Weight
45.00 LBS
Shipping
Free Shipping
Price:
$303.72 RRP:

Description

  • 3 hp 3450 RPM, 12.8 amps, 230V 60 hz.; Reversible
  • NEMA 145T Frame Shaft 7/8" x 2.25"
  • TEAO-Totally Enclosed Air Over; Service Factor=1.0
  • One Year Manufacture Warranty

Totally Enclosed Air Over Motors, dust tight, suitable for shaft mounted fans or belt driven fans. Capacitor start designs. Designed to be used within the airflow of the driven fan, these motors offer protection from the environment and are finished in epoxy enamel to resist corrosion in tough atmospheres. Lubricated with high temperature Exxon POLYREX® EM lubricant. Grounding provisions. Fully gasketed.

PDF Documents
