Bison Model 011-175-0362 Gear Motor 1/20 hp 4.5 RPM 90/130VDC

Part #
011-175-0362
Manufacturer
Bison Gear Motors
Weight
9.00 LBS
Shipping
Calculated at checkout
Price:
$348.98 RRP:

Description

  • 175 Series DC Parallel Shaft Gear Motor - Subject to factory availability-email or call for availability
  • Torque 155 inch pounds
  • Over Hung lbs. = 115
  • 4 Stages
  • Rotation = Reversible
  • 1/20 hp 4.5 RPM, .26 amps, 90 Volts DC
  • TENV Enclosure, Keyed Shaft, Ball Bearings

Optional Accessories: P198-100-9111 Junction Box, P125-100-9998 Mounting Plate. Permanent Magnet motor, Insulation Class B; Finish: Powder-coat gloss black; Brushes: Replaceable; Gearhead Specifications: Housing - Precision machined die cast aluminum; Shafts - Hardened steel; Gearing: Hardened Steel worm. Forged bronze gear; Lubrication: Lifetime oil bath, sealed and gasketed; Any angle mount; Bearings - Ball and Needle Bearings. Suggested replacement reference for: Dayton 2H569. Can use with Leeson speed control 174307, 174308.
