Bison Model 017-175-0096 Gear Motor 1/12 hp 17 RPM 230/460V 60/50HZ.
- Part #
- Bison Gear Motors
- Gift Wrapping
- 10.00 LBS
- Calculated at checkout
- 175 Series AC Parallel Shaft Gear Motor - Subject to factory availability-email or call for availability
- Torque 150 inch pounds; Over Hung lbs. = 150
- Rotation = Reversible; Junction Box Included
- 1/12 hp 17 RPM .60/.35 amps, 230/460V 50/60hz. Three Phase
- TENV Enclosure, Keyed Shaft, Ball Bearings
Gearhead Specifications: Housing: Precision machined die cast aluminum. Lubrication: Lifetime oil bath, sealed and gasketed. Shafts: Hardened steel. Mounting: Face (any angle) or optional footplate. Gearing: 1st stage helical metal, balance spur metal. Bearings: Needle bearings on output shaft. P125-100-9998 Optional Bison Gearmotor Mounting Bracket. One Year Manufacture Warranty. Opening motor voids the warranty.
