Bison Model 017-246-0058 Gear Motor 1/4 hp 29 RPM 230/460V

Part #
017-246-0058
Manufacturer
Bison Gear Motors
Weight
18.00 LBS
Shipping
Calculated at checkout
Price:
$454.63 RRP:

Description

  • 246 Series AC Parallel Shaft Gear Motor - Subject to factory availability-email or call for availability
  • Torque 278 inch pounds; Over Hung lbs. = 273
  • Rotation = Reversible; Junction Box Included
  • 1/4 hp 29 RPM, 1.1/.74 amps; 230/460V Three Phase
  • TEFC Enclosure, Keyed Shaft, Ball Bearings

Motor: Meets NEMA MG 1 sct 31; Powder-coat gloss black; Motor Bearings: Double shielded ball; Thermostat: Signal type; closed. UL/CUL recognized. Gearhead Specifications: Precision machined die cast aluminum ; Lubrication: Lifetime oil bath; Hardened steel shafts; Mounting: Face (any angle) or footplate. Gearing: AGMA class 9 heat treated steel, 1st stage helical metal, balance spur metal. Bearings: Needle with thrust ball. One Year Manufacture Warranty. Opening motor voids the warranty.

PDF Documents
