D10P3D Nidec | 10 hp 1200 RPM 256T Frame 208-230/460V ODP Electric Motor Nidec
D10P3D Nidec | 10 hp 1200 RPM 256T Frame 208-230/460V ODP Electric Motor Nidec
D10P3D Nidec | 10 hp 1200 RPM 256T Frame 208-230/460V ODP Electric Motor Nidec
D10P3D Nidec | 10 hp 1200 RPM 256T Frame 208-230/460V ODP Electric Motor Nidec

Nidec

D10P3D Nidec | 10 hp 1200 RPM 256T Frame 208-230/460V ODP Electric Motor Nidec

(No reviews) Write a Review
$1,676.70
$1,496.96
SKU D10P3D
UPC 6.63E+11
Availability Subject to availability
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 10 HP
RPM 1200
Phase Three Phase
Frame 256T
Enclosure ODP
Hertz 50/60 Hz
Amperage 25.0/12.5 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Continuous Duty
Adding to cart… The item has been added
Description
  • 10 hp 1200 RPM, 25.0/12.5 amps 208-230/460V, 50/60hz. Three Phase
  • NEMA 256T Keyed Shaft 1-5/8" Diameter x 4"
  • ODP; Service Factor: 1.15, Overload protection = None
  • Reversible, Rigid Base Mount, Ball Bearings, Class F Insulation
  • "C" Dimension 21.0"
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a three phase electric motor. Continuous Duty.  Premium efficient. 40C Ambient Temp. Wiring diagram on motor name plate. ODP = Open Drip Proof

Model FP83

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 10 HP
RPM 1200
Phase Three Phase
Frame 256T
Enclosure ODP
Hertz 50/60 Hz
Amperage 25.0/12.5 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Continuous Duty
!
