EE254 Nidec 1/2 HP 3600 RPM 3-Phase 208-230/4600V 56C Frame (No Base) ODP Special Pump Motor
EE254 Nidec 1/2 HP 3600 RPM 3-Phase 208-230/4600V 56C Frame (No Base) ODP Special Pump Motor
EE254 Nidec 1/2 HP 3600 RPM 3-Phase 208-230/4600V 56C Frame (No Base) ODP Special Pump Motor
EE254 Nidec 1/2 HP 3600 RPM 3-Phase 208-230/4600V 56C Frame (No Base) ODP Special Pump Motor

Nidec

EE254 Nidec 1/2 HP 3600 RPM 3-Phase 208-230/4600V 56C Frame (No Base) ODP Special Pump Motor

(No reviews) Write a Review
$303.60
$271.52
SKU EE254
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 1/2 HP
RPM 3600
Phase Three Phase
Frame 56C
Enclosure ODP
Hertz 60 Hz
Amperage 2.2/1.1 Amps
Bearings Ball Bearings
Service Factor 1.25
Insulation Class Class B
Adding to cart… The item has been added
Description

    1/2 hp 3600 RPM, 2.1-2.2/1.1 amps 208-230/460 Volts 60 Hz Three Phase Motor
    NEMA 56C Frame, Keyed Shaft 5/8" Diameter x 1 7/8" Long
    Service Factor: 1.25, Overload protection = None
    Face Mount, Ball Bearings, Class B Insulation, Reversible
    1 Year Manufacture Warranty

Special purpose three phase C- Face motor is usually used in commercial applications involving specialized pumps.  Wiring diagram on motor name plate. ODP = Open Drip-Proof. P055DAP1346015J

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 1/2 HP
RPM 3600
Phase Three Phase
Frame 56C
Enclosure ODP
Hertz 60 Hz
Amperage 2.2/1.1 Amps
Bearings Ball Bearings
Service Factor 1.25
Insulation Class Class B
!
