X2P3B Nidec 2 hp 1200 RPM 184T Frame (Rigid Base) 230/460V TEFC 3-Phase Hazardous Duty Motor
X2P3B Nidec 2 hp 1200 RPM 184T Frame (Rigid Base) 230/460V TEFC 3-Phase Hazardous Duty Motor
X2P3B Nidec 2 hp 1200 RPM 184T Frame (Rigid Base) 230/460V TEFC 3-Phase Hazardous Duty Motor
X2P3B Nidec 2 hp 1200 RPM 184T Frame (Rigid Base) 230/460V TEFC 3-Phase Hazardous Duty Motor

Nidec

X2P3B Nidec 2 hp 1200 RPM 184T Frame (Rigid Base) 230/460V TEFC 3-Phase Hazardous Duty Motor

(No reviews) Write a Review
$1,101.70
$983.48
SKU X2P3B
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 2 HP
RPM 1200
Phase Three Phase
Frame 184T
Enclosure TEFC
Hertz 60 Hz
Amperage 5.8/2.9 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 2 hp 1200 RPM, 5.8/2.9 amps  230/460 Volts 60 Hz Three Phase Motor
  • NEMA 184T Cast Iron frame Keyed Shaft 1 1/8" Diameter x 2 3/4"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose Division 1 hazardous location motor for class 1 group D and class 2 group FG.  Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. FJ14

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 2 HP
RPM 1200
Phase Three Phase
Frame 184T
Enclosure TEFC
Hertz 60 Hz
Amperage 5.8/2.9 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
!
