D30P2DC Nidec 30 hp 1800 RPM 286TC Frame (Rigid Base) 208-230/460V ODP 3-Phase Electric Motor

D30P2DC Nidec 30 hp 1800 RPM 286TC Frame (Rigid Base) 208-230/460V ODP 3-Phase Electric Motor

SKU:
D30P2DC
Weight:
350.00 LBS
Width:
28.00 (in)
Height:
19.00 (in)
Depth:
22.00 (in)
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Voltage:
208/230/460V
Horsepower:
30 HP
RPM:
1800
Phase:
Three Phase
Frame:
286TC
Enclosure:
ODP
Hertz:
50/60 Hz
Amperage:
69/34 Amps
Bearings:
Ball Bearings
Service Factor:
1.15
Insulation Class:
Class F
Mounting:
Rigid Base
Was: $2,502.40
Now: $2,233.99
Adding to cart… The item has been added
  • 30 hp 1800 RPM, 77-69/34 amps 208-230/460 Volts 50/60 Hz Three Phase Motor
  • NEMA 286TC frame Keyed Shaft 1 7/8" Diameter x 4 5/8"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose C-Face motor can be used for many applications requiring a three phase electric motor. Wiring diagram on motor name plate. ODP = Open Drip Proof. DC08

!
