D5V2B Nidec 5 hp 1800 RPM 184T (Rigid Base) 230/460V ODP Inverter-Duty 3-Phase Motor

D5V2B Nidec 5 hp 1800 RPM 184T (Rigid Base) 230/460V ODP Inverter-Duty 3-Phase Motor

SKU:
D5V2B
Weight:
60.00 LBS
Width:
14.00 (in)
Height:
12.00 (in)
Depth:
14.00 (in)
Shipping:
Free Shipping
ON SALE:
LIMITED TIME DISCOUNT
Voltage:
230/460V
Horsepower:
5 HP
RPM:
1800
Phase:
Three Phase
Enclosure:
ODP
Hertz:
60 Hz
Amperage:
12.4/6.2 Amps
Bearings:
Ball Bearings
Speeds:
1-Speed
Service Factor:
1.15
Insulation Class:
Class F
Mounting:
Rigid Base
Was: $680.80
Now: $607.43
Adding to cart… The item has been added
  • 5 hp 1800 RPM, 12.4/6.2 amps 230/460 Volts 60 Hz Three Phase Motor
  • NEMA 184T Rolled Steel Frame with Cast Aluminum End Bells, Keyed Shaft 1 1/8" Diameter x 2 3/4"
  • Service Factor: 1.15 Overload protection = None
  • C-Face Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

Speed controllable motor for material handling, pumps, and fans, in normal environments. 5:1 speed range at constant torque, 20:1 at variable torque. NEMA design B. Brake provisions. Wiring diagram on motor name plate. ODP = Open Drip-Proof. FV34

!
