X40P2B Nidec 40 hp 1800 RPM 324T Frame (Rigid Base) 230/460V TEFC 3-Phase Hazardous Duty Motor

SKU:: X40P2B
UPC:
Weight:: 590.00 LBS
Width:: 34.00 (in)
Height:: 22.00 (in)
Depth:: 26.00 (in)
Shipping:: Calculated at Checkout
ON SALE:: LIMITED TIME DISCOUNT
Voltage:: 230/460V
Horsepower:: 40 HP
RPM:: 1800
Phase:: Three Phase
Frame:: 324T Frame
Enclosure:: TEFC
Hertz:: 60 Hz
Amperage:: 90.0/45.0 Amps
Bearings:: Ball Bearings
Service Factor:: 1.0
Insulation Class:: Class F
Mounting:: Rigid Base

Current Stock:

Was: $4,946.15

Now: $4,416.46

Quantity:

Adding to cart… The item has been added

Description
Compliance & Restrictions

40 hp 1800 RPM, 90.0/45.0 amps 230/460 Volts 60 Hz Three Phase Motor
NEMA 324T Cast Iron frame Keyed Shaft 1 7/8" Diameter x 4 5/8"
Service Factor: 1.0, Overload protection = None
Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
1 Year Manufacture Warranty

General purpose Division 1 hazardous location motor for class 1 group CD and class 2 group FG. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. CU92
