G373 Marathon 1 hp 1800 RPM 56 Frame 115/208-230V Totally Enclosed Marathon Electric Motor

SKU:
G373
Weight:
32.00 LBS
Shipping:
Free Shipping
ON SALE:
DISCOUNTED PRICES AND FREE GROUND SHIPPING
Was: $576.10
Now: $501.70
Adding to cart… The item has been added
  • 1 hp 1800 RPM, 13.4/6.8-6.7 amps 115/208-230 Volts 60hz. Capacitor Start Motor
  • NEMA 56 Frame Keyed Shaft 5/8" Diameter x 1 7/8"
  • Service Factor: 1.15, Overload protection = Manual
  • Reversible, Rigid Base Mount, Ball Bearings, Class B Insulation
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a single phase electric motor. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled

Marathon # 056C17F5311
Replaces Leeson M6C17FB8K, 110023.00
