HB0254 TECO-Westinghouse 25 hp 1800 RPM 284T 460V TEFC Severe Duty Petro-Chem 3-Ph Motor

SKU:
HB0254
Weight:
555.00 LBS
Shipping:
Calculated at Checkout
$2,319.37
Adding to cart… The item has been added

TECO WESTINGHOUSE, NEMA PREMIUM ELECTRIC MOTOR

  • 25 hp 1800 RPM, 29.1 amps 460 Volts 60 Hz Three Phase
  • NEMA 284T Frame, 4 5/8 x 1 7/8" Dia. Keyed Shaft
  • Cast Iron Frame, Totally Enclosed Fan Cooled (IP56)
  • Service Factor: 1.15, Thermal Overload Protection: None
  • Rigid Base, Reversible, Ball Bearings, Class F Insulation
  • Suitable for Inverter Use per NEMA MG-1 Part 31.4.4.2
  • Inverter Duty Speed Range: 20:1 Variable Torque, 10:1 Constant Torque
  • Motors are U.L. Recognized, CSA Approved and CE Marked
  • 1 Year Manufacture Warranty

Part of the E2-E841 family of motors. For use in Severe Duty Petro-Chemical Applications Having Explosive Gases. Certified for Class 1, Division 2, Groups B,C,D
