YC32P2B Nidec 1 1/2 hp 1800 RPM 145T Frame (Rigid Base) 230/460V TEFC 3-Phase Div 1 Hazardous Duty Motor

YC32P2B Nidec 1 1/2 hp 1800 RPM 145T Frame (Rigid Base) 230/460V TEFC 3-Phase Div 1 Hazardous Duty Motor

SKU:
YC32P2B
Weight:
80.00 LBS
Width:
16.00 (in)
Height:
10.00 (in)
Depth:
13.00 (in)
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Voltage:
230/460V
Horsepower:
1/2 HP
RPM:
1800
Phase:
Three Phase
Frame:
145T
Enclosure:
TEFC
Hertz:
60 Hz
Amperage:
4.3/2.1 Amps
Bearings:
Ball Bearings
Service Factor:
1.15
Insulation Class:
Class F
Mounting:
Rigid Base
Was: $1,105.15
Now: $986.24
Adding to cart… The item has been added
  • 1 1/2 hp 1800 RPM, 4.3/2.1 amps 230/460 Volts 60 Hz Three Phase Motor
  • NEMA 145T Cast Iron frame Keyed Shaft 7/8" Diameter x 2 1/4"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose, Corrosion resistant, Division 1 hazardous location motor for class 1 group D.  Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. CP13

!
