FF60E1GS Nidec 60 hp 3600 RPM 575V ODP 324TS (Rigid Base) 3-Phase Fire Pump Motor

FF60E1GS Nidec 60 hp 3600 RPM 575V ODP 324TS (Rigid Base) 3-Phase Fire Pump Motor

SKU:
FF60E1GS
Weight:
447.00 LBS
Width:
29.00 (in)
Height:
21.00 (in)
Depth:
24.00 (in)
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Voltage:
575V
Horsepower:
60 HP
RPM:
3600
Phase:
Three Phase
Enclosure:
ODP
Hertz:
60 Hz
Amperage:
54.0 Amps
Bearings:
Ball Bearings
Service Factor:
1.15
Insulation Class:
Class F
Mounting:
Rigid Base
Was: $5,526.90
Now: $4,934.77
Adding to cart… The item has been added
  • 60 hp 3600 RPM, 54.0 amps 575 Volts 60 Hz Three Phase Motor
  • NEMA 324TS Rolled Steel Frame, Keyed Shaft 1 7/8" Diameter x 4 1/4"
  • Service Factor: 1.15 Overload protection = None
  • C-Face Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

For fire pump applications per NFPA 20 where contaminants are minimal. Wiring diagram on motor name plate. ODP = Open Drip Proof. S769

!
