HD7P1H Nidec 7 1/2 hp 3600 RPM 215T Frame (Rigid Base) 200-208V TEFC 3-Phase Electric Motor

HD7P1H Nidec 7 1/2 hp 3600 RPM 215T Frame (Rigid Base) 200-208V TEFC 3-Phase Electric Motor

SKU:
HD7P1H
Weight:
130.00 LBS
Width:
22.00 (in)
Height:
13.00 (in)
Depth:
18.00 (in)
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Voltage:
200-208V
Horsepower:
1/2 HP
RPM:
3600
Phase:
Three Phase
Frame:
215T Frame
Enclosure:
TEFC
Hertz:
60 Hz
Amperage:
20.1 Amps
Bearings:
Ball Bearings
Service Factor:
1.15
Insulation Class:
Class F
Mounting:
Rigid Base
Duty:
Inverter Duty
Was: $811.90
Now: $724.85
Adding to cart… The item has been added
  • 7 1/2 hp 3600 RPM, 20.6-20.1 amps 208-230 Volts 60 Hz Three Phase Motor
  • NEMA 215T Cast Iron frame Keyed Shaft 1 3/8" Diameter x 3 3/8"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

Hostile duty motor can be used for many applications requiring a three phase electric motor. Inverter Duty. Self-certified Class 1, Division 2, Groups A, B, C, D. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. GE07

!
