FF60E1GV Nidec 60 hp 3600 RPM 3-phase 326JP Frame 575V ODP Vertical Close-Coupled Fire Pump Motor

FF60E1GV Nidec 60 hp 3600 RPM 3-phase 326JP Frame 575V ODP Vertical Close-Coupled Fire Pump Motor

SKU:
FF60E1GV
Weight:
460.00 LBS
Width:
18.00 (in)
Height:
34.00 (in)
Depth:
24.00 (in)
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Voltage:
575V
Horsepower:
60 HP
RPM:
3600
Phase:
Three Phase
Frame:
326JP Frame
Enclosure:
ODP
Hertz:
60 Hz
Amperage:
54.0 Amps
Bearings:
Ball Bearings
Insulation Class:
Class F
Rotation:
Reversible
Was: $8,396.15
Now: $7,496.62
Adding to cart… The item has been added
  • 60 HP 3600 RPM, 54.0 amps, 575V 60 Hz, 3 Phase.
  • NEMA 326JP Rolled Steel Frame, JP stainless steel shaft
  • 1.15 Service Factor, Class F insulation
  • Reversible Rotation,
  • Face Mount, No Base, Ball Bearings,

Meets NFPA 20 standards. Close Coupled motors have the pump impeller mounted directly on the shaft. 1 Year Manufacture Warranty. ODP = Open Drip Proof, AD34

!
